MARINE EQUIPMENT Parts & Accessories ELECTRONICS & NAVIGATION GENERAL BOATING SAFETY WATERSPORTS & BOATS TROLLING & FISHING SEATING ANCHORING/MOORING COVERS / TOPS TRAILERING MAINTENANCE PAINT ELECTRICAL VENTILA TION HARDWARE FASTENERS PLUMBING STEERING PROPS & ANODES No portion of this catalog may be reproduced or copied without written permission. Please note pricing may change without notice. The content in this catalog is correct to the best of our knowledge but is subject to change if updates become available from the manufacturers.We are not responsible for typographical errors, omissions, or any other errors regarding content, selection, pricing or description. Please note product lines affected by tariffs may result in price increases and are subject to change. Each year we proudly introduce new items into our diverse line of marine parts and accessories. Look for this icon and the BLUE item numbers to see what’s NEW for 2022! 2022 ENGINE FUEL NUMERIC INDEX ALPHA INDEX

ULTIMA® provides excellent antifouling protection for both power and sailboats at an economical price. Ultima’s surface wears away over time, eliminating build up or the need for sanding. It can be used on most previously painted surfaces in good condition. One or two coats per season are recommended for optimal performance. UNEXPOXY HRT® seasonal antifouling uses the latest technology available to create a hybrid paint film strong enough to handle the tough marine environment without building up over time. It is a dependable antifouling paint formulated to provide outstanding protection at a very affordable price. Its smooth, durable finish is able to withstand beaching, trailering, and season-long abuse. HORIZONS® offers excellent protection from fouling along with all of the benefits of ablative paints. Economically priced, it performs well in all conditions, including severe fouling waters. A heavy load of copper provides dependable, multi-season performance. Its ablative surface wears away with use, exposing fresh biocides while eliminating paint build up and the need for sanding. Can be launched and re-launched without repainting making it an excellent choice for trailered boats. BLUE - 1281 RED - 1681 BLACK - 1881 BLUE - 1250 GREEN - 1350 ANTIFOULING BOTTOM PAINT BLUE - 1211 RED - 1611 BLACK - 1811 RED - 1650 BLACK - 1850 NEW ANTIFOULING Fiberglass Bottomkote ACT Micro CSC Ultima Horizons Premium Performance Horizons Ultima Unepoxy HRT LIGHT SAND & APPLY LIGHT SAND & APPLY LIGHT SAND & APPLY SAND & APPLY SAND & APPLY SAND & APPLY REMOVE LIGHT SAND & APPLY REMOVE REMOVE REMOVE REMOVE HEAVY SAND & APPLY HEAVY SAND & APPLY SAND & APPLY Tri-Lux II Epoxycup F/G Bottomkote Unepoxy Bottomkote XXX VC 17(m) VC 17(m) Extra VC Offshore Baltoplate OLD ANTIFOULING PETTIT BOTTOM PAINT COMPATIBILITY CHART

DO THE JOB RIGHT. USE ONLY TINNED COPPER WIRE. • Long-lasting and rugged – exceed UL 1426, ABYC and USCG standards • Insulation rated at 600 volts, 105°C/221°F dry and 75°C/167°F wet • Stays flexible even in extreme cold (-40°F/C) • Resists salt water, battery acid, oil, gasoline, heat, abrasion and UV radiation • Highest quality, ultra-flexible (Type 3) tinned copper stranding provides maximum protection against corrosion and electrolysis • Resists fatigue due to vibration and flexing Purple Orange Gray Brown Dark Blue White Green Yellow Red Black • Marine grade, premium UL1426 tinned copper battery cable and lugs • Fine stranded to produce maximum conductivity and flexibility • Flame and UV resistant • Rated to 600 volts and 105°C / 221°F • Each end features adhesive lined 3:1 heatshrink tubing placed over the electrical connection to seal out moisture and other corrosive elements • Heatshrink tubing provides strain relief for longerlasting battery connection TINNED COPPER BATTERY CABLE ASSEMBLIES Red Black GAUGES FROM 18-2 New Reversible Cooling Towels • UPF 50 sun protection • Stay cool for hours when wet • Soft and absorbent when dry • Reusable and machine washable • Durable, 100% polyester dries quickly • Chemical-free • Size: 12" x 39" Model 48100 Blue Model 48101 Green Model 48102 Gray Face Wraps New • UV protection • Dry quickly • Durable Model 48001 Waves Model 48004 Marlin Model 48002 Mahi Model 48005 Compass Rose Model 48003 Bass Model 48006 T-Map

With a subscription to the Quicksilver University continuing technical education program, you can enhance your service capabilities and earning potential without needing to send technicians away for training. Benefits of a Quicksilver University subscription: • Unlimited access to training programs plus exclusive technical webinars and chat opportunities through your distributor • Opportunity to learn at your own pace with dozens of remote classes, videos and webinars • Eligibility for an enhanced warranty rate for Quicksilver and Mercury® Remanufacturing products • Ability to offer a broader range of repower, repair and maintenance services to satisfy more customers • Printable course completion certificates (for select courses) to display at your business • Learn to service the industry’s leading brands of sterndrive and inboard engines, includingMercury Remanufacturing, MerCruiser® and Quicksilver How to Enroll 1. Purchase or renew an annual Quicksilver University subscription through your distributor. 2. Once you subscribe, you’ll receive login credentials and can immediately begin participating. Ask your distributor for more information. Subscribe, Learn and Earn! Subject areas include: • Fuel-Injection and EFI systems • In-depth failure analysis • Extended storage procedures •Water ingestion • Corrosion prevention and repair •Prop selection and setup Subscribe Now: QuicksilverUniversity.com © 2021 Mercury Marine. All Rights Reserved. Reproduction in whole or in part without permission is prohibited.

Item Numbers in Red are hazardous items in blue are new ] sea value v oversized d COURIER Surcharge GENERAL BOATING WATERSPORTS & bOATS SEATING COVERS/TOPS MAINTENANCE ELECTRICAL HARDWARE PLUMBING PROPS & aNODES FUEL ELECTRONICS & NAVIGATION SAFETY TROLLING & fISHING ANCHORING/ mOORING TRAILERING PAINT VENTILATION FASTENERS STEERING ENGINE 1 ELECTRONICS In-Dash Digital Depth & Air Temperature Gauges Item# Type Color Transducer 678-12850 Euro Black Transom 678-12851 Euro Black In-Hull 678-13150 Dress White Transom 678-13151 Dress White In-Hull 678-13750 Chesapeake SS Black Transom 678-13751 Chesapeake SS Black In-Hull 678-13795 Chesapeake SS Black Thru-Hull 678-13850 Chesapeake SS White Transom 678-13851 Chesapeake SS White In-Hull With an oversized back-lit display depth can be easily read in any weather condition. Audible and visual alarms let the boater know when a shallow or deep water condition exist. A programmable keel offset lets you adjust the offset from the keel at the display. Features: •  Depth Range: 199' •  Deep and Shallow water alarms •  Programmable Keel off-set •  Back lighting for night vision •  Automatic Gain control •  Metric or US standard units •  Easy to install •  Includes transducer w/20' of cable •  Fits 2 1/16" standard gauge hole DIGITAL DEPTH SOUNDER Chesapeake SS White Chesapeake SS Black Dress White Euro Black Item# Type Color Transducer 678-13752 Chesapeake SS Black Transom 678-13852 Chesapeake SS White Transom This unique dual temperature depth sounder has all the same features as the standard Faria digital depth sounders plus it reads both air and water temperatures from 32º F to 200º F. Mounts in a standard 2 1/16" diameter gauge hole and reads depth to 199 feet, 61 meters, or 32 fathoms with both deep and shallow water alarms. Keel offset allows you to program the unit to read the depth from the keel of the boat for better accuracy. The 2-line, backlit display is easy to read in all conditions. DIGITAL DEPTH SOUNDER WITH AIR & WATER TEMPERATURE 13852 13752 Item# Type 678-SN2060A In-Hull With a low profile this depth unit offers little drag and easy installation for dead rise angles up to 30°. Designed with a release bracket to protect against impact damage. This unit provides good high speed operations up to 55 knots. SN2060 DEPTH TRANSDUCER Includes advanced sonar, depth alarm, and keel offset capabilities and also integrates dual temperature displays and an ultra-sensitive, high-performance transducer. A simple press of a button produces instant access to water or air temperature readings via integrated sensors in both the head unit and the transducer. Max depth range is 600'. Item# Transducer 835-DT2BXTM Transom Mount •  SoftGlow™ Backlit display and programming keys •  No Glare, Polarized LCD Icon Display •  Includes black and white face plates & trim rings •  3-stage Advanced Warning System™ •  Selectable Imperial or Metric Readout •  Algorithmic programming significantly reduces false readings •  Standard 2" gauge size DEPTHTRAX™ 1BX DEPTH FINDER Item# Transducer 835-DT2BTM] Transom Mount Able to reach depths of 600' and tuned for high speed performance, the DepthTrax 2B reaches deeper and performs faster. Keel offset adjustment. Depth readings are updated 4 times per second. No glare, polarized LCD icon SoftGlow™ backlit display and programming keys •  Includes black and white face plates & trim rings •  3-stage Advanced Warning System™ •  Selectable Imperial or Metric Readout •  Algorithmic programming significantly reduces false readings •  Standard 2" gauge size DEPTHTRAX™ 2B DEPTH FINDER Item# Transducer 137-4078601] Transom The HDR 650 gives you the performance you need with depth readings to 600' at speeds up to 70 mph. It mounts in a standard 2 1/8" diameter hole and includes 2 face plates (White & Black) and 3 trim rings (Black, White, & Silver) for your own custom look. Completely waterproof, it features a large, 1 1/4" backlit LCD display, shallow & deep alarms, and reads in feet/fathoms/meters. Includes a transommount transducer. HDR650 DIGITAL DEPTH GAUGE Item# 11-26000P •  Depth range of 600 feet / 200 meters •  Speeds up to 60 mph •  No glare LCD display •  Dual Depth Alarm •  White & Black interchangeable faces •  Black, white & chrome interchangeable bezels •  High speed 200 kHz transducer can be transom or in-hull glue mounted •  Keel Offset •  Limited Lifetime Warranty 2" IN-DASH DIGITAL DEPTH FINDER Item# A B C Volts 354-4216181 1 7/16" 1 1/16" 1 1/8" 12/24 LED ROUND TEMPERATURE METER Monitors temperature on a bright LED screen. Same compact round size as a standard 12 VDC receptacle for many installation options. Installation is as easy as drilling a 1 1/8" hole, inserting the socket body, tightening the locking nut, and connecting the wires. Includes a prewired temperature sensor with a 6' cable. Reverse polarity protected. IP67 waterproof rating. Injection molded nylon.

Items are stocked in our warehouses based on regional demand. If an item is not in stock at a local warehouse, additional charges may apply. GENERAL BOATING WATERSPORTS & bOATS SEATING COVERS/TOPS MAINTENANCE ELECTRICAL HARDWARE PLUMBING PROPS & aNODES FUEL ELECTRONICS & NAVIGATION SAFETY TROLLING & fISHING ANCHORING/ mOORING TRAILERING PAINT VENTILATION FASTENERS STEERING ENGINE ELECTRONICS 2 Item# Description A B C Volts 354-4216101 Temp Meter 1 7/16" 3/4" 1 1/8" 12-24 Opt. Accy. Description Size 354-4261061 Rear Socket Boot 1 1/8" ID x 1 7/8"L OLED AIR TEMPERATURE METER OLED (Organic LED) Temperature Meter is designed to withstand constant vibration and the rigors of a wet marine or dusty outback environment. Monitors temperature on a bright, waterproof, daylight readable OLED screen. High contrast and resolution make this screen visible from a wide viewing angle, even with polarized sunglasses. Reverse polarity protected. Injection molded nylon construction. Includes a prewired temperature sensor with a 6’ cable. IP66 rating. Garmin Ice Fishing Products Item# Display Resolution 322-0100234215 9" 800 x 480 •  Revolutionary real-time sonar allows you to see up to 200’ in any direction •  Panoptix LiveScope system with two scanning sonar modes •  LiveScope Forward sonar shows up to 200’ all around you and below the ice •  LiveScope Down sonar shows moving sonar images of what is below the ice •  Comes preloaded with LakeVü g3 maps with integrated Navionics® data, covering more than 18,000 U.S. lakes •  Built-in flasher provides accurate jig and fish detection •  Create custom pages that combine Panoptix™ sonar, flasher and map •  Rugged, portable carrying case In The Box: ECHOMAP™ UHD 93sv chartplotter, Panoptix™ LiveScope System, Panoptix ice fishing mount, Tilt/ swivel mount, Power cable, Bag with handle, Rechargeable battery, Battery charger. PANOPTIX™ LIVESCOPE ICE FISHING BUNDLE Item# 322-0101267620 Includes everything needed to take your 7” or 9” ECHOMAP Plus combo and transform your ice fishing experience. Kit Includes: •  Panoptix PS22-TR transducer with both LiveVü Forward and LiveVü Down modes •  GT10HN-IF ice fishing transducer w/ CHIRP traditional sonar with selectable narrow beam angle (8°-16°) •  Rugged, glove-friendly case •  Also includes Panoptix transducer swivel pole mount, foam float and cable grommet, 12Ah battery, charger, power cable and transducer adapter Fishfinder sold separately, see Garmin website for compatibility PANOPTIX™ ICE FISHING KIT Item# 322-0101267650 Includes everything needed to take your compatible ECHOMAP™ or GPSMAP® unit from your boat onto the ice and transform your fishing experience. Kit Includes: •  Panoptix™ LiveScope System •  Panoptix ice fishing mount •  Tilt/swivel mount •  Power cable •  Portable Bag with handle •  Rechargeable battery •  Battery charger Fishfinder sold separately, see Garmin website for compatibility PANOPTIX™ LIVESCOPE ICE FISHING KIT Item# 322-0101246210 This glove-friendly, easy-to-carry kit includes a high-wide CHIRP transducer plus a battery with charger and other components to easily transition from your boat to the ice. To complete the kit, just add your compatible STRIKER™ or ECHOMAP™ unit. Kit Includes: •  GT8HW-IF transducer •  Power cable •  Bag with handle •  Foam float •  Cable grommet •  Rechargeable battery •  Battery charger Fishfinder sold separately, see Garmin website for compatibility SMALL PORTABLE ICE FISHING KIT This glove-friendly, easy-to-carry kit includes a high-wide CHIRP transducer plus a battery with charger and other components to easily transition from your boat to the ice. To complete the kit, just add your compatible STRIKER™ or ECHOMAP™ unit. Item# 322-0101267600 Kit Includes: •  GT10HN-IF transducer •  Bag with handle •  Foam float •  Transducer adapter cable •  Cable grommet •  Rechargeable battery •  Battery charger •  Power cable and 8-pin to 4-pin transducer adapter cable Fishfinder sold separately, see Garmin website for compatibility LARGE PORTABLE ICE FISHING KIT Item# 322-0101267605 Rugged, glove-friendly bag and base carries and protects your ECHOMAP™ Plus 9” combo and Panoptix LiveScope™ System. EXTRA LARGE CARRY BAG & BASE Item# Material Type 322-0101240120 Plastic GT8HW-IF (4 pin) Perfect for ice fishermen who want clear bottom definition as well as crisp, clear and wide fish arches with excellent target separation. The wider beam width (up to 24°) provides a larger coverage area in the water. The 4-pin transducer features high wide band CHIRP traditional sonar (150-240 kHz) with a power rating of 250 W. It's shape and beam widths have been optimized for ice fishing and feature a silicon-coated cable that remains flexible in harsh winter conditions. ICE FISHING HIGH WIDE CHIRP TRANSDUCER Item# 322-0101267700 Perfect for fishermen who want clear definition under the ice with excellent target separation. The narrow, 7°-16° beam angle provides precise fish and jig detection. 500 Watt 8-pin high-narrow CHIRP traditional sonar transducer with shape and beam widths optimized for ice fishing. Silicone-coated transducer cable remains flexible in harsh winter conditions. Includes a 8-pin to 4-pin transducer adapter cable, foam float and grommet. GT10HN-IF ICE FISHING TRANSDUCER Item# 322-0101267610 This pole mount allows you to rotate your Panoptix PS22-TR LiveVü Forward and Down transducer, while under the ice, to locate fish around you. The mount can go to about 4.25' (maximum depth) below the surface. PANOPTIX ICE FISHING POLE MOUNT

Item Numbers in Red are hazardous items in blue are new ] sea value v oversized d COURIER Surcharge GENERAL BOATING WATERSPORTS & bOATS SEATING COVERS/TOPS MAINTENANCE ELECTRICAL HARDWARE PLUMBING PROPS & aNODES FUEL ELECTRONICS & NAVIGATION SAFETY TROLLING & fISHING ANCHORING/ mOORING TRAILERING PAINT VENTILATION FASTENERS STEERING ENGINE 3 ELECTRONICS Item# 322-0101267615 Position your Panoptix LiveScope™ LVS32 transducer on this 0° pole mount for an optimal viewing angle while ice fishing (works for open water fishing too). 0 DEGREE LIVESCOPE POLE MOUNT Item# 322-0101267640 Connect your Panoptix™ LiveScope System or Panoptix PS22 transducer and compatible ECHOMAP chartplotter to the battery of your compatible Panoptix ice fishing bundle with this power cable. It also includes a convenient charge port plug and 10A fuse holder. Compatible with the Panoptix™ LiveScope Ice Fishing Bundle. PANOPTIX™ POWER CABLE Garmin Fishfinders/GPS/Chartplotters & Network Systems Item# Description 322-0100224600 STRIKER™ Cast 322-0100224602 STRIKER™ Cast GPS CASTABLE SONAR TURNS PHONES INTO FISHFINDERS. Easily find and catch more fish with the durable STRIKER Cast sonar device. Just cast it out, and reel it back in to view sonar with a 200’ castable range via an app display on your smartphone or tablet. •  Streams and displays sonar on a simple phone app •  Download the free app for your Apple or Android •  Works in freshwater or saltwater and for ice fishing •  Available with Built-in GPS that provides the ability to create custom Quickdraw fishing maps with 1’ contours •  Select from easy-to-interpret traditional 2-D sonar and ice fishing flasher modes •  Selectable fish icons to view graphic images of fish targets and their depth readings •  10+ hours of rechargeable battery life Includes: STRIKER Cast, Carry bag, 5m Tether, USB charging cable. STRIKER™ CAST CASTABLE SONAR STRIKER™ Cast GPS STRIKER™ Cast Item# Display Size 322-0100155000] 3.5" Finding fish is easier than ever with STRIKER 4 fishfinder. Share your favorite waypoints and routes with other STRIKER and echoMAP™ combos. Smooth Scaling™ graphics provide uninterrupted imagery when switching between depth-range scales. Sonar history rewind allows you to scroll back through sonar images to mark waypoints you originally may have missed. Plus, it has a built-in flasher and displays speed data. •  Easy-to-use color fishfinder w/built-in, high-sensitivity GPS •  Find fish; mark and return to hot spots, docks and ramps •  Convenient keypad operation •  Includes CHIRP (77/200 kHz) sonar transducer; transmit power (200 W RMS)/(1,600 W peak-to-peak), with transom/trolling motor mount and a tilt/swivel mount. •  Upgrade to high performance CHIRP w/GT8 or GT15 transducer (sold separately) STRIKER™ 4 FISHFINDER W/GPS Item# Model Display 322-0100255001 4cv WW w/ GT20-TM Transducer 4" 322-0100255000] 4cv US w/ GT20-TM Transducer 4" 322-0100255102 5cv WW No Transducer 5" 322-0100255101 5cv WW w/ GT20-TM Transducer 5" 322-0100255100] 5cv US w/ GT20-TM Transducer 5" 322-0100255302 7sv WW No Transducer 7" 322-0100255201 7cv WW w/ GT20-TM Transducer 7" 322-0100255200] 7cv US w/ GT20-TM Transducer 7" 322-0100255300] 7sv US w/ GT52HW-TM Transducer 7" 322-0100255402 9sv WW No Transducer 9" 322-0100255401 9sv WW w/ GT52HW-TM Transducer 9" 322-0100255400 9sv US w/ GT52HW-TM Transducer 9" See fish and structure in maximum detail when you pick your display color, your location and your sonar. •  Choose from 7 new vivid color options •  Waypoint marking for hot spots •  Plan and create routes and view your boat’s speed w/GPS •  Quckdraw contours, store up to 2 million acres of maps with 1’ contours •  Includes a tilt/swivel mount plus transom and trolling motor mounting hardware and cable STRIKER™ Vivid cv: CHIRP traditional sonar and CHIRP ClearVü STRIKER™ Vivid sv: CHIRP traditional sonar plus CHIRP ClearVü and CHIRP SideVü STRIKER™ VIVID SERIES FISHFINDER 5", 7", 9" 4" Item# Model Description Display 322-0100188705]PLUS 45CV w/GT20-TM Transducer Canada LakeVü™ HD 4" 322-0100189501 PLUS 77CV w/GT23M-TM Transducer BlueChart® g3 Canada 7" ClearVü & Traditional Chirp: Includes transducer for Garmin CHIRP traditional sonar plus CHIRP ClearVü™ scanning sonar with transom and trolling motor mounts, compatible with Panoptix™ all-seeing sonar (sold separately) •  Bright, sunlight-readable display •  Built-in Quickdraw Contours software creates personalized fishing maps with 1' contours •  Use built-in Wi-Fi® to pair with the free ActiveCaptain™ app for access to OneChart™, smart notifications, Garmin Quickdraw™ Community data and more •  Share waypoints and routes with other ECHOMAP™ or STRIKER™ units EchoMAP™ PLUS SERIES CHARTPLOTTER/SONAR COMBO 7" 4"

Items are stocked in our warehouses based on regional demand. If an item is not in stock at a local warehouse, additional charges may apply. GENERAL BOATING WATERSPORTS & bOATS SEATING COVERS/TOPS MAINTENANCE ELECTRICAL HARDWARE PLUMBING PROPS & aNODES FUEL ELECTRONICS & NAVIGATION SAFETY TROLLING & fISHING ANCHORING/ mOORING TRAILERING PAINT VENTILATION FASTENERS STEERING ENGINE ELECTRONICS 4 Item# Model Description Display Size 322-0100189901 PLUS 77SV w/GT51M-TM Transducer BlueChart® g3 Canada 7" 322-0100190301 PLUS 97SV w/GT51M-TM Transducer BlueChart® g3 Canada 9" SideVü, ClearVü & Traditional Chirp: Garmin high wide CHIRP traditional sonar plus CHIRP ClearVü™ and CHIRP SideVü™ scanning sonars and compatible with Panoptix™ all-seeing sonar (sold separately). •  Bright, sunlight-readable keyed-assist touchscreen combo •  Built-in Quickdraw Contours mapping software instantly creates personalized fishing maps on-screen with 1' contours as you fish •  Use built-in Wi-Fi® to pair with the free ActiveCaptain™ app for access to OneChart™, smart notifications, Garmin Quickdraw™ Community data and more EchoMAP™ PLUS SV SERIES CHARTPLOTTER/SONAR COMBO 9" 7" Item# Model Display ECHOMAP™ UHD 6" Chartplotter/Sonar Series w/ClearVü 322-0100233200 65cv w/GT24UHD-TM Xducer & Canada LakeVü g3 6" ECHOMAP™ UHD 7" Chartplotter/Sonar Series w/ClearVü 322-0100233501] 74cv w/GT24UHD-TM Xducer & U.S. BlueChart® g3 7" 322-0100233600 75cv w/GT24UHD-TM Xducer & Canada LakeVü g3 7" ECHOMAP™ UHD 7" Chartplotter/Sonar Series w/SideVü & ClearVü 322-0100251801 72sv w/o Xducer w/ Worldwide Basemap 7" 322-0100251901] 73sv w/GT56UHD-TM Xducer & U.S. LakeVü g3 7" 322-0100252001] 74sv w/GT56UHD-TM Xducer & U.S. BlueChart® g3 7" 322-0100252100 75sv w/GT56UHD-TM Xducer & Canada LakeVü g3 7" ECHOMAP™ UHD 9" Chartplotter/Sonar Series w/SideVü & ClearVü 322-0100252201 92sv w/GT56UHD-TM Xducer & Worldwide Basemap 9" 322-0100252301] 93sv w/GT56UHD-TM Xducer & U.S. LakeVü g3 9" 322-0100252401] 94sv w/GT56UHD-TM Xducer & U.S. BlueChart® g3 9" 322-0100252500 95sv w/GT56UHD-TM Xducer & Canada LakeVü g3 9" A bright, sunlight-readable touchscreen with keyed assist. It features a quick-release bail mount. NMEA 2000® and NMEA 0183 network support provides you with engine data, sensor connection, autopilot integration and more. ECHOMAP™ UHD 7" & 9" Models are compatible with the Force™ trolling motor for full control of the motor from the screen plus the ability to route to waypoints, follow tracks and more. Plus Panoptix™ all-seeing sonar, including Panoptix LiveScope™ sonar capable. They also have sonar sharing capabilities with other ECHOMAP™ Plus, ECHOMAP UHD and ECHOMAP Ultra units. ECHOMAP™ UHD cv Series Features ClearVü scanning sonar and Garmin high wide CHIRP traditional sonar capability. ECHOMAP™ UHD sv Series: Features Ultra High-Definition SideVü & ClearVü scanning sonar and Garmin high wide CHIRP traditional sonar capability. ECHOMAP™ UHD CV & SV SERIES CHARTPLOTTER/SONAR sv 9" sv 7" cv 7" cv 6" Bright, sunlight-readable keyed-assist touchscreen display. Select combo units include an all-in-one transducer for CHIRP traditional and Ultra High-Definition ClearVü and SideVü scanning sonars. Supports optional premium BlueChart® g3 charts and BlueChart g3 Vision cartography with integrated data from Navionics®. Item# Model Description Display ECHOMAP™ Ultra Series 10" GPS/Chartplotters 322-0100252601] 102sv w/ Worldwide Basemap & GT56UHD-TM Transducer 10" 322-0100252701] 106sv w/Bluechart® G3 & Lakevu G3 & GT56UHD-TM Transducer 10" ECHOMAP™ Ultra Series 12" GPS/Chartplotters 322-0100252801] 122sv w/Worldwide Basemap & GT56UHD-TM Transducer 12" 322-0100252901] 126sv w/Bluechart® G3 & Lakevu G3 & GT56UHD-TM Transducer 12" •  Built-in support for the full line of Panoptix™ sonars and the Panoptix LiveScope™ scanning sonar system •  Share sonar, waypoints and routes with other ECHOMAP Ultra 10” and 12” units as well as ECHOMAP Plus 7” and 9” units •  Built-in Quickdraw Contours mapping software instantly creates personalized fishing maps on-screen with 1’ contours •  Built-in Wi-Fi® connectivity pairs with the free ActiveCaptain® app •  NMEA 2000® connectivity and support for heading sensors, autopilots, digital switching, FUSION-Link™ audio system and more ECHOMAP™ ULTRA SERIES GPS/CHARTPLOTTER/SONAR

Item Numbers in Red are hazardous items in blue are new ] sea value v oversized d COURIER Surcharge GENERAL BOATING WATERSPORTS & bOATS SEATING COVERS/TOPS MAINTENANCE ELECTRICAL HARDWARE PLUMBING PROPS & aNODES FUEL ELECTRONICS & NAVIGATION SAFETY TROLLING & fISHING ANCHORING/ mOORING TRAILERING PAINT VENTILATION FASTENERS STEERING ENGINE 5 ELECTRONICS Item# GARMIN_FULL_ECHOMAP UHD_1* ECHOMAP™ UHD2 CHARTPLOTTERS Fish like a local with a GT20-TM transducer. See clear, sharp fish arches with Garmin traditional sonar. Use ClearVü scanning sonar featuring vivid color palettes for clear, high-contrast views below your boat. Know the waters you’re in as if you grew up fishing them by using built-in LakeVü g3 inland maps. • Intuitive keyed chartplotters with bright sunlight-readable screens • Ability to connect wirelessly with another ECHOMAP UHD2 chartplotter to share sonar, waypoints and routes • Pair with the free all-in-one ActiveCaptain® app on a compatible smartphone for access to the OneChart™ feature, software updates and more FEATURING ECHOMAP UHD2 55cv, Canada LakeVü with GT20 xdcr 322-0100259200 ECHOMAP UHD2 75cv, Canada LakeVü with GT20 xdcr 322-0100259600

Items are stocked in our warehouses based on regional demand. If an item is not in stock at a local warehouse, additional charges may apply. GENERAL BOATING WATERSPORTS & bOATS SEATING COVERS/TOPS MAINTENANCE ELECTRICAL HARDWARE PLUMBING PROPS & aNODES FUEL ELECTRONICS & NAVIGATION SAFETY TROLLING & fISHING ANCHORING/ mOORING TRAILERING PAINT VENTILATION FASTENERS STEERING ENGINE ELECTRONICS 6 Item# Model Display Resolution GPSMAP® 7" GPS/Charplotters 322-0100236500 723 Non-sonar w/Worldwide Basemap 7" 1024 x 600 322-0100236501]743 Non-sonar w/Bluechart® G3 & LakeVÜ G3 7" 1024 x 600 322-0100236502 723xsv w/SideVü, ClearVü and Traditional CHIRP Sonar & Worldwide Basemap 7" 1024 x 600 322-0100236503 743xsv w/SideVü, ClearVü and Traditional CHIRP Sonar & Bluechart® G3 & LakeVÜ G3 7" 1024 x 600 322-0100236550 723xsv w/GMR™ 18 HD+ Radome, SideVü, ClearVü and Traditional CHIRP Sonar & Worldwide Basemap 7" 1024 x 600 322-0100236551]743xsv w/GMR™ 18 HD+ Radome, SideVü, ClearVü and Traditional CHIRP Sonar & Bluechart® G3 & LakeVÜ G3 7" 1024 x 600 GPSMAP® 9" GPS/Charplotters 322-0100236600 923 Non-sonar w/Worldwide Basemap 9" 1280 x 720 322-0100236601]943 Non-sonar w/Bluechart® G3 & LakeVÜ G3 9" 1280 x 720 322-0100236602 923xsv w/SideVü, ClearVü and Traditional CHIRP Sonar & Worldwide Basemap 9" 1280 x 720 322-0100236603]943xsv w/SideVü, ClearVü and Traditional CHIRP Sonar & Bluechart® G3 & LakeVÜ G3 9" 1280 x 720 322-0100236650 923xsv w/GMR™ 18 HD+ Radome, SideVü, ClearVü and Traditional CHIRP Sonar & Worldwide Basemap 9" 1280 x 720 322-0100236651 943xsv w/GMR™ 18 HD+ Radome, SideVü, ClearVü and Traditional CHIRP Sonar & Bluechart® G3 & LakeVÜ G3 9" 1280 x 720 GPSMAP® 12" GPS/Charplotters 322-0100236700]1223 Non-sonar w/Worldwide Basemap 12" 1280 x 800 322-0100236701]1243 Non-sonar w/Bluechart® G3 & LakeVÜ G3 12" 1280 x 800 322-0100236702 1223xsv w/SideVü, ClearVü and Traditional CHIRP Sonar & Worldwide Basemap 12" 1280 x 800 322-0100236703]1243xsv w/SideVü, ClearVü and Traditional CHIRP Sonar & Bluechart® G3 & LakeVÜ G3 12" 1280 x 800 322-0100236750 1223xsv w/GMR™ 18 HD+ Radome, SideVü, ClearVü and Traditional CHIRP Sonar & Worldwide Basemap 12" 1280 x 800 322-0100236751 1243xsv w/GMR™ 18 HD+ Radome, SideVü, ClearVü and Traditional CHIRP Sonar & Bluechart® G3 & LakeVÜ G3 12" 1280 x 800 w/Radome With 60% more display pixels and nearly double the processing power of previous-generation GPSMAP devices, these crisp high-resolution chartplotters integrate seamlessly into your Garmin marine system. •  Slimline design featuring edge-to-edge glass and a smaller footprint. •  Improved sunlight readability with 60% more pixels than previous-generation. •  Garmin Marine Network-share information such as maps, user data, radar and IP camera video on compatible devices. •  NMEA 2000® & NMEA 0183-Connect to compatible autopilots, digital switching, weather, Fusion-Link™ audio system, media, VHF, AIS and more. •  ActiveCaptain® APP-Built-in Wi-Fi® connectivity for access to the OneChart™ feature, smart notifications, software updates, Garmin Helm™ digital switching, Garmin Quickdraw™ Community data and more. •  Intergrated ANT® Technology-Connect with some of your favorite devices, such as quatix® marine watches, gWind™ Wireless 2 transducers, GNX™ Wind marine instruments and wireless remote controls. •  J1939 Connectivity-connect your chartplotter to many different engines. •  OneHelm™ Feature-all the operations and capabilities of select third-party devices, such as EmpirBus™ digital switching, on one screen. •  Panoptix™ Sonar Support-Pair with Panoptix PS51 (transducer sold separately) with FrontVü scanning sonar. •  xsv Models Feature: built-in Ultra High-Definition SideVü and ClearVü scanning sonars. •  xsv Models with Radar Bundle Feature: includes the compact 4 kW GMR™ 18 HD+ dome radar GPSMAP® 7X3/9X3/12X3 SERIES GPS/CHARTPLOTTER) Item# Model Description Display 322-0100174003 1042xsv w/o Transducer 10" 322-0100174021 1042xsv w/GT52 Transducer 10" 322-0100174121 1242xsv w/GT52 Transducer 12" Experience an advanced all-in-1 solution with our GPSMAP keyed combo. Available with or without a transducer for Garmin CHIRP sonar, CHIRP ClearVü and CHIRP SideVü. It also has built-in support for Panoptix all-seeing sonar and premium Garmin sonar modules (transducers sold separately). Features a large, bright screen with a quick and easy-to-use keypad interface with user programmable keys and a multifunction control knob. Garmin Marine Network support allows sharing of sonar, maps, user data, dome or open-array radar, IP cameras and Panoptix sonar among multiple units. Includes NMEA 2000® network connectivity and NMEA 0183 support for autopilots, digital switching, weather, media, VHF, AIS and other sensors. Enjoy built-in Wi-Fi connectivity for BlueChart Mobile 2.0 and Garmin Helm apps. •  Preloaded U.S. LakeVü HD maps and BlueChart® g3 HD charts •  High-sensitivity internal 10 Hz GPS and GLONASS receiver 1042xsv 10": 12.5" W x 7.3" H x 2.7" D 1242xsv 12": 14.1" W x 8.9" H x 2.7" D GPSMAP® 1042xsv/1242xsv GPS/CHARTPLOTTERS

Item Numbers in Red are hazardous items in blue are new ] sea value v oversized d COURIER Surcharge GENERAL BOATING WATERSPORTS & bOATS SEATING COVERS/TOPS MAINTENANCE ELECTRICAL HARDWARE PLUMBING PROPS & aNODES FUEL ELECTRONICS & NAVIGATION SAFETY TROLLING & fISHING ANCHORING/ mOORING TRAILERING PAINT VENTILATION FASTENERS STEERING ENGINE 7 ELECTRONICS GPSMAP® 8600 SERIES GPS/CHARTPLOTTER W/TOUCHSCREEN Item# Model Description Display 322-0100209301 GPSMAP® 8616 Chartplotter w/BlueChart® g3 U.S. coastal and LakeVü HD Mapping 16" 322-0100209303 GPSMAP® 8616xsv Chartplotter w/BlueChart® g3 U.S. coastal and LakeVü HD Mapping & Sonar 16" Serious sport fishermen, cruisers, sailors and sail racers demand serious equipment. The easy-to-use, easy-to-install GPSMAP 8600-Series delivers MFD performance in a combo-size package. They feature a full HD IPS touchscreen display for wider viewing angles, superior clarity and sunlight readability, even with polarized sunglasses. Multiple displays can be flat mounted edge-to-edge to create a sleek glass helm look or can be mounted flush. xsv Chartplotter/Sonar combo: built-in support for our sonar, including dual-channel 1 kW traditional CHIRP, CHIRP ClearVü and CHIRP SideVü scanning sonars plus built-in support for Ultra High-Definition scanning sonar (no black box required). It also supports the entire Panoptix™ all-seeing sonar line (transducers sold separately). •  Full HD IPS touchscreen display preloaded with both BlueChart® g3 U.S. coastal and LakeVü HD maps featuring Navionics® data and Auto Guidance¹ technology •  Fully network capable with NMEA 2000® and the Garmin Marine Network •  Built-in support for the full suite of Garmin sonar capabilities •  Includes ANT® technology and Wi-Fi® networking •  SmartMode™ station controls for quick, one-touch access to information 16" w/Sonar Garmin Remote Sounder Modules Item# 322-0100095700 With up to 2,000 Watts of transmit power and a highdynamic range receiver, the GSD 24 brings high-definition imaging to your compatible Garmin chartplotter. The system is dual frequency (50/200 kHz) capable and offers selectable transmit power (600 W, 1 kW and 2 kW, depending on transducer) for pin-point accuracy at depths of up to 5,000 ft (1,500 m). So whether you're out sportfishing or just keeping an eye on hazardous terrain and reef structures beneath your boat, you'll see a clearer picture with enhanced separation of images and deeper bottom detection. Once connected, your sonar data will be shared on any compatible chartplotter on the network. Plus, the network's high-speed connections ensure that you get ultra-fast screen updates with minimal delay. Features: vastly improved digital sonar design for superior target definition and deep-water performance. GSD24 DIGITAL REMOTE SOUNDER Just Add Monitor(s)! Fully integrate features across your entire marine system. This black box system is compatible with a single Garmin marine monitor or third-party touchscreen monitor (sold separately). Item# 322-0100209400 •  Full support for the range of Garmin black box sonar products •  Pairs with external GPS 19x 10 Hz GPS and GLONASS receiver •  Preloaded worldwide basemap; compatible with BlueChart® g3 charts •  Integrates internal sonar sharing, multiple black box sonars, Ultra High-Definition ClearVü and SideVü scanning sonars, autopilot, connected services, apps, engine data and more GPSMAP® 8700 BLACK BOX Garmin Transducers, Mounts & Accessories Item# 322-0100216400 Enjoy added security and awareness on your vessel. •  Monitor 1 or more areas above and below deck in clear, real-time HD video •  HD resolution for excellent images, even in low light •  Stream video from up to 4 cameras at a time •  Use reverse-image setting on compatible chartplotters to help back out of tight locations •  Connect and share video across multiple compatible chartplotters •  Power: 10 - 16 VDC or over Garmin marine network through the Power and Audio Module (010-12527-00) sold separate) •  Camera connection: Garmin Marine Network •  Images: Standard and reversed; rotated 90,180 or 270 •  Night vision: Built-In IR LEDs •  Night vision distance: Up to 30 meters •  Viewing angle: 99° horizontal/74° vertical •  Image sensor: 2.0 megapixel •  Resolution: Up to 1920 x 1080 pixels •  Video output: H.264 over GMN •  Operating temperature: -20C to 60C •  Water rating: IPX7 GC™ 200 MARINE IP CAMERA Item# kHz Material Type Transom Mount Transducer 322-0101024940 77/200 Plastic D, 8 Pin 322-0101027200 50/200 Plastic D,T, 6 Pin 322-0101027210 50/200 Plastic D,T, 8 Pin D = Depth, S = Speed, T = Temperature GARMIN TRANSDUCERS 0101027200 0101024940 Item# Description 322-0101098221 8° - 15° deadrise angles 322-0101098220 16°- 24° deadrise angles Dual frequency (50/200 kHz) transducer is specially designed to provide a vertical beam without a fairing block. The ceramic element is tilted to provide deadrise compensation. The resulting vertical beam provides excellent echo returns for more accurate depth readings. The nearly flush housing minimizes drag with only 3/16" extending outside of the hull. Includes a built-in temp sensor and handles up to 600 watts (RMS) power. Includes 39' cable. B60 TILTED ELEMENT BRONZE THRU-HULL TRANSDUCER Item# Description kHz 322-0100196110 Single 455/800 322-0100196111 Port & Starboard Pair 455/800 Perfect for the fisherman who wants CHIRP ClearVü and CHIRP SideVü scanning sonar with a stainless steel stem, this 12-pin thru-hull transducer consistently displays clear definition of objects, structure and fish below and to each side of the boat. The transducer with built-in fast response temperature sensor has a power rating of 500 W per element (1,500 W total); a depth of 750' (ClearVü) and 500' left and right (SideVü); for hull deadrises less than 5°. Pair it with your GCV™ 10 scanning sonar module. GT30 CHIRP ClearVü & SideVü THRU-HULL TRANSDUCER Port & Stbd Pair Single Item# kHz Type 322-0101277600 800/1200 Transom Mount Add stunningly clear Ultra High-Definition ClearVü and Ultra High-Definition SideVü scanning sonar images to your compatible chartplotter. Plug directly into your 8600xsv or ECHOMAP Ultra series chartplotter or use the GCV 20 sonar module to display on other compatible chartplotters. It includes 3 arrays, including a downward-facing element, with frequencies ranging from 800 kHz to 1,200 kHz. GT34UDH-TM CHIRP ClearVü & SideVü TRANSOM MOUNT TRANSDUCER

Items are stocked in our warehouses based on regional demand. If an item is not in stock at a local warehouse, additional charges may apply. GENERAL BOATING WATERSPORTS & bOATS SEATING COVERS/TOPS MAINTENANCE ELECTRICAL HARDWARE PLUMBING PROPS & aNODES FUEL ELECTRONICS & NAVIGATION SAFETY TROLLING & fISHING ANCHORING/ mOORING TRAILERING PAINT VENTILATION FASTENERS STEERING ENGINE ELECTRONICS 8 Item# 322-0101307200 Offers ultimate versatility, featuring Ultra High-Definition ClearVü and SideVü scanning sonars for crystal-clear images of fish and structure. •  SideVü sonar now has 20% greater range at 1,000 kHz, so you can see even farther than before •  Delivers 455 kHz, 800 kHz and 1,000 kHz for top performance •  High-contrast vivid scanning sonar color palettes to distinguish targets and structure •  Includes transom and trolling motor mounting hardware GT36UHD-TM ClearVü & SideVü TRANSOM MOUNT TRANSDUCER Item# Model 322-0101240210 GT15M-TM Perfect for fishermen who want clear bottom definition under the boat as well as crisp, clear and wide fish arches with excellent target separation to depth up to 1,900'. The 8-pin transducer features mid-band CHIRP traditional sonar (85-165 kHz) and has a power rating of 600 W. TRANSOM MOUNT MID-BAND CHIRP TRANSDUCER Item# Material Type 322-0101240400 Plastic GT23M-TM (8 pin) 322-0101240410 Stainless Steel GT23M-TH (8 pin) Perfect for coastal and offshore fishermen who want CHIRP traditional sonar and CHIRP DownVü scanning sonar. Consistently displays clear and crisp fish arches with superior target separation as well as clear definition of structure below the boat. The 8-pin transducer features mid-band CHIRP traditional sonar (80-160 kHz) and has a power rating of 600 W. The CHIRP DownVü (260/455 kHz) element has a power rating of 500 W. For installation, follow the included instructions carefully to avoid damaging your boat. TRANSOM MOUNT MID-BAND CHIRP DOWNVU TRANSDUCER Stainless Plastic Item# Material Type 322-0101240500 Plastic GT52HW-TM (12 pin) Perfect for freshwater fishermen who want CHIRP traditional sonar and CHIRP ClearVü scanning sonar. Consistently displays clear and crisp fish arches with superior target separation as well as clear definition of structure below the boat. Ideal for mounting to a trolling motor. Includes installation instructions. •  The 12-pin transducer features high wide band CHIRP traditional sonar and has a power rating of 250 W. The CHIRP ClearVü and CHIRP SideVü (455/800 kHz) elements have a power rating of 350 W each (1,050 W total) TRANSOM OR TROLLING MOTOR MOUNT HIGH WIDE CHIRP DOWNVU/SIDEVU TRANSDUCER Item# Description 322-0100196000 GT20-TM (4 pin) 322-0100196001 GT20-TM (8 pin) Perfect for the shallow water fisherman who want traditional and CHIRP ClearVü scanning sonar, this transom or trolling motor mounted transducer consistently displays fish arches as well as clear pictures of objects, structure and fish that pass below your boat. The 20 ft transducer cable with built-in fast response temperature sensor has a power rating of 500 W; a depth of 1,900 ft (traditional) and 750 ft (ClearVü); an operating frequency of 77/200 kHz (traditional) and 455 kHz (ClearVü); and a 0 to 70 transom angle. Transducer comes with transom and trolling motor mounts, and installation instructions. Follow the instructions carefully to avoid damaging your boat. TRANSOM OR TROLLING MOTOR MOUNT CHIRP DOWNVU TRANSDUCER Item# Material Type 322-0101240200 Plastic GT15M-IH (8 pin) IN-HULL MID-BAND CHIRP TRANSDUCER Ideal for installing inside a fiberglass hull. It can be used with a hull deadrise angle between 0° and 25° by using 1 of 4 included "tanks". The 8-pin transducer features mid-band CHIRP traditional sonar (85-165 kHz) and has a power rating of 600 W. It can be used in conjunction with a GT30-TM transducer and an adapter cable so you can maintain depth at high speeds and scanning capabilities at trolling speeds. For installation, follow the included instructions carefully to avoid damaging your boat. Item# Model 322-0101240110 GT8HW-IH Ideal for bass boats or any fast boat that wants to install the transducer inside a fiberglass hull and not on the transom. It requires a flat section in the hull and is excellent for boats traveling at high speeds. The 8-pin transducer features high-wide CHIRP traditional sonar (150-240 kHz) and has a power rating of 250 W. It can be used in conjunction with a GT30-TM transducer and an adapter cable (sold separately) so you can maintain depth at high speeds and scanning capabilities at trolling speeds. IN-HULL HIGH-WIDE BAND CHIRP TRANSDUCER Item# kHz Type 322-0100196610 CHIRP DownVü/SideVu 260/455 Traditional Mid band: 80/160 GT51M-TH(12 pin) This thru-hull transducer provides ultra-clear sonar pictures of objects, structure and fish that pass below your boat. This traditional CHIRP sonar and CHIRP DownVü/SideVü transducer is optimized for depth performance and rough conditions. It includes a built-in fast-response temperature sensor. For hull deadrises less than 5 degrees. GT51MTH includes: 12-pin transducer with stainless steel stem, fairing block, isolation plate and bushings, mounting hardware and installation instructions. THRU HULL TRANSDUCER Item# Model kHz Beam 322-0101193722 B175H 130-210 6°-10° Flush-mounted bronze housing protrudes less than 1/4" and can sit on the trailer rollers/bunks without damage. The tilted element inside the transducer accommodates all hull deadrises and eliminates the need for a fairing block. An excellent choice for fiberglass and wood hulls. Follow the installation instructions carefully to avoid damaging your boat. BRONZE 20° TILTED THRU-HULL CHIRP TRANSDUCER WITH DEPTH & TEMP Item# Material Type 322-0101240120 Plastic GT8HW-IF (4 pin) Perfect for ice fishermen who want clear bottom definition as well as crisp, clear and wide fish arches with excellent target separation. The wider beam width (up to 24°) provides a larger coverage area in the water. The 4-pin transducer features high wide band CHIRP traditional sonar (150-240 kHz) with a power rating of 250 W. It's shape and beam widths have been optimized for ice fishing and feature a silicon-coated cable that remains flexible in harsh winter conditions. ICE FISHING HIGH WIDE CHIRP TRANSDUCER Item# 322-0101267700 Perfect for fishermen who want clear definition under the ice with excellent target separation. The narrow, 7°-16° beam angle provides precise fish and jig detection. 500 Watt 8-pin high-narrow CHIRP traditional sonar transducer with shape and beam widths optimized for ice fishing. Silicone-coated transducer cable remains flexible in harsh winter conditions. Includes a 8-pin to 4-pin transducer adapter cable, foam float and grommet. GT10HN-IF ICE FISHING TRANSDUCER

Item Numbers in Red are hazardous items in blue are new ] sea value v oversized d COURIER Surcharge GENERAL BOATING WATERSPORTS & bOATS SEATING COVERS/TOPS MAINTENANCE ELECTRICAL HARDWARE PLUMBING PROPS & aNODES FUEL ELECTRONICS & NAVIGATION SAFETY TROLLING & fISHING ANCHORING/ mOORING TRAILERING PAINT VENTILATION FASTENERS STEERING ENGINE 9 ELECTRONICS Item# Model Description 322-0101290800 GT24UHD-TM ClearVü Transducer 322-0101290900 GT54UHD-TM ClearVü and SideVü Transducer •  One transducer provides the highest resolution scanning sonar images available •  High wide CHIRP traditional sonar provides remarkably clear target separation and definition •  Compact, all-in-one design includes transom and trolling motor mounts •  Compatible with GPSMAP® 8400xsv/8600xsv and ECHOMAP™ Ultra chartplotter/ sonar combos GT24UHD-TM ClearVü: See incredibly detailed images of fish and structure up to 200’ below your boat with 800 kHz ClearVü sonar GT54UHD-TM ClearVü & SideVü: Two SideVü sonar frequency settings (455/1200 kHz) provide options for extended range of up to 500’ and up to 200’ below your boat with 800 kHz ClearVü sonar ULTRA HIGH DEFINITION ALL-IN-ONE TRANSDUCER Item# Model 322-0101278403 LVS32 Transom or Trolling Motor Mount Part of the Panoptix LiveScope System, it requires the GLS 10 sonar black box to function. Includes both LiveScope™ Down and LiveScope™ Forward modes in one transducer. It’s easy to adjust the transducer mode to fit your fishing techniques; use LiveScope Forward to see remarkably clear images of structure and swimming fish around your boat, and use LiveScope Down to see directly below your boat. •  20° x 135° Beam width •  Forward view shows structure and fish in real time up to 200’; down view shows structure and fish up to 200’ •  Includes Attitude Heading Reference System (AHRS) for a stable view in rough conditions PANOPTIX LIVESCOPE™ LVS32 TRANSDUCER Item# 322-0100128400 With the Panoptix Down transducer, you can actually see fish and bait swimming around under your boat in real time, even while stationary. You get 3 remarkable views: LiveVü Down, RealVü 3-D Down and RealVü 3-D Historical. •  LIVEVÜ DOWN: Provides real-time moving sonar images. You can see fish swimming toward or away from the boat. You can see small baitfish and large target fish swimming around, even your lure. •  REALVÜ 3-D DOWN: Allows your boat to be stationary and still see things in 3-D around your boat. It shows history of only 1 sweep. •  REALVÜ 3-D HISTORICAL: Used for finding fish while your boat is moving. This shows the entire water column you have passed over in 3-D, from the bottom of the surface and all of the fish in between. PANOPTIX™ PS30 DOWN TRANSDUCER Item# Type 322-0100186400] Transom or Trolling Motor Mount 322-0100223300 Thru-hull Mount Easy-to-interpret live scanning sonar images of fish near clearly defined structure. You can even see your lure as you retrieve it. Your boat doesn’t need to be moving. Clear and precise images. •  Incredibly sharp real-time sonar images up to 200’ away •  Attitude Heading Reference System (AHRS) stabilizes sonar view on chartplotter •  Simple plug-and-play connector to seamlessly integrate with your compatible Garmin chartplotter (visit www.garmin.com for compatible units) •  Transom mount easily adjusts to point forward to see around your boat, or down to see below your boat PANOPTIX LIVESCOPE™ SYSTEM Thru-Hull Mount Transom Mount Item# 322-0101297000 The Perspective Mode Mount takes your Panoptix LiveScope™ real-time scanning sonar to the next level. Attach your LVS32 transducer to this mount to add an overhead sonar view that’s perfect for scouting and fishing in shallow water. •  1 Mount, 3 views - see all around your boat in real time •  Easily mounts to your trolling motor •  Your chartplotter automatically detects which mode you’re in •  Rough waters won’t affect sonar PANOPTIX LIVESCOPE™ PERSPECTIVE MODE MOUNT Item# 322-0101267610 This pole mount allows you to rotate your Panoptix PS22-TR LiveVü Forward and Down transducer, while under the ice, to locate fish around you. The mount can go to about 4.25' (maximum depth) below the surface. PANOPTIX ICE FISHING POLE MOUNT Item# 322-0101267615 Position your Panoptix LiveScope™ LVS32 transducer on this 0° pole mount for an optimal viewing angle while ice fishing (works for open water fishing too). 0 DEGREE LIVESCOPE POLE MOUNT Item# 322-0101267640 Connect your Panoptix™ LiveScope System or Panoptix PS22 transducer and compatible ECHOMAP chartplotter to the battery of your compatible Panoptix ice fishing bundle with this power cable. It also includes a convenient charge port plug and 10A fuse holder. Compatible with the Panoptix™ LiveScope Ice Fishing Bundle. PANOPTIX™ POWER CABLE Item# 322-0101240600 Reduces excessive water spray from your compatible transducer when your boat is running at high speeds. TRANSDUCER SPRAY SHIELD Item# Length Type 322-0101161732 10' 12-pin 322-0101161742 30' 12-pin Extend the length of your compatible 12-pin transducer with these cables. Supports 12-pin Airmar transducers with XID. SCANNING TRANSDUCER EXTENSION CABLE Item# Length Type 322-0101161710 10' 4-pin 322-0101161750 10' 8-pin Extend the cable length of your compatible transducer. TRANSDUCER EXTENSION CABLE Item# 322-0101161300 This adapter allows you to connect the wires on legacy 6-pin transducers with newer sonar that require a 8-pin connection. TRANSDUCER ADAPTER WIRE BLOCK
